K DAC

特色

R-2R電阻陣列式音頻解碼器
继承了高端型号 SagraDAC 的 DSP/DA 转换和输入/输出部分
小巧尺寸,只有212mm寬
最高支持384KHz/24bit和原生DSD256
I2S輸入端口
紅外線遙控器
可切换數位濾波器
數位音量控制
煲機模式
浮地功能
DC供電端口,可使用線電或電池供電

K-DAC 採用開關電源,從而降低了成本並節省了空間,使眾多音訊愛好者能夠透過 R-2R 方式享受音樂。儘管採用開關電源,但音質毫不妥協;它旨在提供最佳音質,包括使用 Eleven Audio 的原廠 AC-DC 模組。

輸入介面及支援的格式:
* USB:44.1kHz ~ 384kHz/32bit / DSD64 ~ DSD256(原生,DoP)

支援的作業系統:
Windows 7/8/10,Mac OS 10.6.8 或更高版本符合 USB 音訊類別 2.0 標準:在 Windows 系統下可透過 ASIO Native 播放 DSD 音頻,在 Mac OS 系統下可透過 DoP 播放 DSD 音訊。Windows 10 驅動程式:https://amanero.com/drivers/combo384_drivers_w10_1062.zipWindows 7/8 驅動程式:https://amanero.com/drivers/combo384_drivers_xp_win7_win8_1057.zip*微軟已停止對 Windows 7/8 的支持,因此我們不提供對這些作業系統的支援。Mac OS 10.6.8 或更高版本:使用作業系統自帶的驅動程式。

* HDMI(相容 I2S - PS Audio):32kHz ~ 384kHz/32bit / DSD64 ~ DSD256
S/PDIF RCA1 75Ω:32kHz ~ 192kHz/24bit(內建隔離器)
S/PDIF BNC 75Ω:32kHz ~ 96kHz/24bit
Toslink:32kHz ~ 96kHz/24bit
AES/EBU 110Ω:32kHz ~ 96kHz/24bit
S/PDIF BNC、TOSLINK 和 AES/EBU 輸入皆支援去加重處理。

輸出介面:1 個 XLR/RCA 介面(可同時使用)
輸出電壓:XLR 4Vrms,RCA 1.4Vrms-1dBFS
總諧波失真:0.008%, -60dBFS 總諧波失真:0.03%
抖動(RMS):典型值 0.8 pS
動態範圍:130.5dB
訊號雜訊比:127dB
電源電壓:AC100V / 110V / 220V
外部電源輸入:12V/1A 或更高
尺寸:212 x 62 x 156 毫米(寬/高/深,不含凸起部分)
重量:1.6 公斤

為什麼叫K DAC?

K來自Key這個詞。在音樂中,Key代表調性。我們常說的C大調像白色、E大調像黃色、a小調像純藍色。Key非常影響音樂的色彩。

在音樂中,Key也用於代表某個調式的主音。這也符合我對解碼器(DAC)在音響系統中的定位。我一向認為,音響系統中,解碼器(DAC)是決定整個系統上限的最關鍵因素。就好像大師手中的那把Stradivari名琴,沒有那把Stradivari名琴,再好的錄音和回放都失去靈魂。K DAC是桌面小型系統的核心,是Key Point, 是關鍵。

K DAC從高階機型SagraDAC下放了丹麥Soekris定制R-2R解碼核心,展現XIAUDIO的音樂美學和來自丹麥的成熟技術。可以直接推動主動式喇叭,或組成小型的頂級水準耳機系統。

K DAC可以攜帶移動。追求極端的發燒友甚至可以用電池直接供電。

K DAC採用了數字電源和線性電源組合的方式組成供電系統。共9個供電電路給各部分分別供電。

神秘的AC/DC電源模組,Nichicon音頻專用電容,成本最高的義大利Amanero原裝USB介面模組,極限優化的供電系統,配合R-2R架構,帶來驚人的音樂表現力。

K comes from the word "key." In music, key represents tonality. We often say C major is like white, E major is like yellow, and A minor is like pure blue. Key greatly influences the color of music.In music.

key is also used to represent the tonic of a key. This aligns with my view of the decoder (DAC) in an audio system. I've always believed that in an audio system, the decoder (DAC) is the most crucial factor determining the overall system's upper limit. Like a Stradivarius violin in the hands of a master, without that Stradivarius, even the best recording and playback lose their soul. The K DAC is the core of a small desktop system; it's the key point, the crucial element.

The K DAC utilizes a custom-designed R-2R decoding core from the high-end SagraDAC, showcasing XIAUDIO's musical aesthetics and mature Danish technology. It can directly drive active speakers or form a small, top-tier headphone system.

The K DAC is portable. Extreme audiophiles can even power it directly with batteries.

The K DAC employs a combination of digital and linear power supplies in its power supply system. A total of 9 power supply circuits provide power to each component.

A mysterious AC/DC power module, Nichicon audio-grade capacitors, the highest-cost Italian Amanero original USB interface module, an extremely optimized power supply system, and an R-2R architecture deliver amazing musical performance.
